Solder Fume Extraction

Why are solder (chemical fumes, odors) fume extractors important:

People can become permanently sensitized to solder fumes. As a result continued exposure may cause asthma and other respiratory health issues depending on the amount of exposure. Employees should be protected from these health risks by using the best fume extraction systems available.

Why fume extraction is essential for personnel:

Worker safety is critically important in soldering applications. A well-designed and maintained dust and fume collection system is needed to prevent respiratory problems and keep facilities in compliance with current air-quality standards. In some cases, a good dust collection and ventilation system can eliminate the need for personal respirators and the challenge of getting employees to wear them.

Why should companies use fume extraction systems:

Many industrial processes such as soldering, laser processing and welding all produce dust and fumes which are hazardous to health and which can also reduce productivity or increase rejected products. Fumes can also damage expensive production equipment and cause extensive downtime for repair and/or cleaning. Many local and international health and safety regulations require the employer to protect personnel from hazardous dust and fumes. Failure to do so can result in expensive compensation claims and fines.

Possible health symptoms due to soldering smoke

■ headaches;
■ fatigue;
■ irritability;
■ constipation;
■ nausea;
■ stomach pains;
■ amnesia
■ dizzyness;
■ loss of weight.

Continued uncontrolled exposure could cause far more serious symptoms such as:

■ kidney damage;
■ nerve and brain damage.
■ cancer

SolderPure


Solder Fume Filtration   Description


  • Designed for workstations with multiple soldering stations
  • Heavy Duty General Purpose units capture SOLDER SMOKE & FUMES at source, before they migrate throughout the room
  • Ideal for: SOLDER FUMES, FLUX, WAXING FUMES, SOLVENT VAPORS (Isopropenal - cleaning)
  • Higher static allows for remote installation of up to 4 soldering stations
  • whisper quiet
  • | more info |

SolderPureHD


High Capacity Solder Fume Filtration   Description

  • Heavy Duty General Purpose units capture SOLDER SMOKE & FUMES at source, before they migrate throughout the room
  • Ideal for: SOLDER FUMES, FLUX, WAXING FUMES, SOLVENT VAPORS (Isopropenal - cleaning)
  • Higher static capability & higher filtration capability than conventional SolderPure
  • Higher static allows for remote installation
  • Optional Foot-pedal simplifies operation (PN: H181-Universal, or PN: H251-deluxe soft-touch)
  • One Multi-Flex Arm included
  • | more info |

SPH-Mini


Laser, Soldering & Welding   Description


  • Mini filter system captures solder smoke & fumes at source, before they migrate troughout the room
  • Compact and extremely quiet ( 52 dba )
  • Cost effective bench top soldering fume extractor
  • Single capture arm capabilities
  • Up to 4 stations using 1" piping, 2 stations using 2" piping and 1 station using 3" piping or capture arm
  • Filters easily accessed and changed in less than 1 minute ( no tools required )
  • Flexible ESD safe source capture arms and various nozzles to suit the application
  • Sleek, powder coated durable welded cabinet
  • Recirculating purified air reduces heating and air conditioning cost
  • 3-stage filter system incorporates pleated pre-filter, carbon and 99.97% HEPA filters.
  • | more info |

CollectAll


Hybrid Brushless Dust Collector   Description

  • Designed for solder applications that as well as solder fumes create significant dust or debris
  • New hybrid, high suction motor technology
  • With collection bag, HEPA & Odor filter & brushless Hi-Pressure motor
  • 3-stage filtration captures all particulates
  • Whisper quiet operation is office friendly
  • Optional Caster Kit: PN: AS025
  • | more info |

SPH-400


Multi Purpose Filtration Station   Description

  • Captures solder smoke & fumes at source using small diameter tip extraction
  • Ideal for up to 10 soldering irons
  • High pressure system is economical
  • Whisper quiet ( 52 dba )
  • Compact installation requiring no bulky and expensive ductwork
  • Filters easily accessed and changed in less than 1 minute ( no tools required )
  • Powder coated durable welded cabinet
  • Recirculating purified air reduces heating and air conditioning cost
  • | more info |

SPH-800


Multiple Station Filtration   Description

  • Capture solder smoke & fumes at source using small diameter tip extraction
  • Ideal for up to 20 soldering irons
  • High pressure system is economical
  • Whisper quiet ( 52 dba )
  • Compact installation requiring no bulky and expensive ductwork
  • Filters easily accessed and changed in less then 1 minute ( no tools required )
  • Powder coated durable welded cabinet
  • Recirculating purified air reduces heating and air conditioning cost
  • | more info |

FreshAir


Reflow Wave Soldering Systems   Description

  • Cleans, purifies and freshens all room air
  • Collects particles down to 0.3 sub-micron levels
  • Filters 100% of all room air every 4 minutes
  • Removes all odors and airborne dust particles
  • Three models available for different size areas
  • AF600 for up to approx. 350-400 sq.ft.(<36m2 )
  • AF1000 for up to approx. 500-600 sq.ft .(<56m2 )
  • AF2000 for up to approx. 1000-1200 sq.ft. .(<111m2 )
  • | more info |

DCS


Desktop Containment System   Description

  • Eliminates Odor, Vapors and Particulate Matter migrating through-out the workplace
  • perform your soldering inside DCS Containment Station
  • Illuminated work area
  • Small footprint friendly
  • Designed for quiet operation
  • Can be ducted to the outside
  • | more info |

DFS


Desktop Filter System   Description

  • System can be used for multiple applications including chemical touch up, paints glue and coating processes as well as soldering
  • No venting to the outside required
  • 3 stage system with multiple filter arrangements available
  • Pad filter, 2" 99.97% HEPA, 2" carbon filter removes dust, odors and harmful vapors
  • 100% fully adjustable fan speed control
  • | more info |

Info subject to change without notice
